Home Ugoos Products X4 TV Box Family Series Devices based on Android 11

X4 TV Box Family Series Devices based on Android 11

DESCRIPTION SPECIFICATION DOWNLOADS (9)

X4 TV Box Family Series Devices based on Android 11

X4 Family is a continuation of X3 bestseller. As before, we have different options for any task:

X4 Cube 2G+16G Android 11 Amlogic S905X4 Smart TV Box

X4 Pro 4G+32G Android 11 Amlogic S905X4 Smart TV Box

X4 Plus 4G+64G Android 11 Amlogic S905X4 Smart TV Box

Description:

Ugoos X4

Hardware Spec:

Hardware Specs*:
Operation System	Android 11
Language	English, Chinese ...Multi-Language support
CPU	Amlogic S905X4 with Quad-Core Cortex-A55 12nm
GPU	ARM Mali-G31MP2 Open GL ES 3.2 Vulkan 1.0
SDRAM	LPDDR4 2GB or 4GB for X4 Pro and X4 Plus
Storage Capacity (Flash)	16GB （EMMC） or 32GB for X4 Pro and 64GB for X4 Plus
WIFI	2.4G+5G The wireless module complies with IEEE 802.11 a/b/g/n/ac support 2T2R MiMO technology
Bluetooth	Bluetooth 4.0 with LE technology
The Extended Storage	TF Card, up to 32GB (SD2.X,SD3.X,SD4.X, eMMC ver5.0)
Power Supply	DC 5V/2.5A via USB Type - C
HDR	Support
Interfaces:
HDMI Output	HDMI 2.0 Type-A Support maximum 4Kx2K@60fps 10Bit + 1080P60 10Bit
	1USB 3.0, 1USB 2.0 Host
Optical Output	1*SPDIF
Led Work Light	Support
Network	1*RJ45 1000M (1000M Ethernet Integrated IEEE 802.3 10/100/1000M Ethernet MAC with RGMII interface)
Power Supply	1* USB Type - C Jack
Media Parameter:
Audio Container	MP3,AAC,WMA,RM,FLAC,OGG
Audio Out	Supports MP3, AAC, WMA, RM, FLAC, Ogg Built-in serial digital audio SPDIF/IEC958 output and PCM input/output Built-in stereo audio DAC, Stereo digital microphone PDM input Support concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM
Video CODEC	AV1 Video Codec Support – VP9 Profile-2 up to 4Kx2K@60fps – AV1 MP-10@L5.1 up to 4Kx2K@60fps – H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps – AVS2-P2 Profile up to 4Kx2K@60fps – H.264 AVC HP@L5.1 up to 4Kx2K@30fps – MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) – WMV/VC-1 SP/MP/AP up to 1080P@60fps – AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps – MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) – MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) – RealVideo 8/9/10 up to 1080P@60fps – Multiple language and multiple format sub-title video support – MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) – Supports JPEG thumbnail, scaling, rotation and transition effects – Supports .mkv,.wmv,.mpg, .mpeg, .dat, .avi, .mov, .iso, .mp4, .rm and *.jpg file formats
Software Extension	Support Google Play & APK install
DLNA, Miracast Protocol	Support DLNA, Miracast Protocol
Remote Control	Remote controller
IM Software	Support Skype/QQ/MSN/GTALK (Depends on APK ）
Office Software	WORD/EXCEL/PDF(Depends on APK install)
Other Parameters:
Humidity Environment	5%-90%(No condensation）
Certificate	CE, FCC
Package:
Dimensions	1106222mm
Net Weight	460g
Gift Box Size	15510085mm

* Devices' parts or equipment may be changed without additional notification.

Downloads:

Android 11 firmware V. 1.1.7 for Ugoos X4 Family

1. Added option to turn off always visible Bluetooth
2. Fixed Bluetooth remote controller connection lost after shutdown by air mouse
3. Fixed text input by mouse in settings
4. Fixed focus reset in application selection window
5. Fixed support of some applications
6. Changed screen saver and energy saver timers setting
7. Now one-shot timer always resets after any power action
8. Added framebuffer size setting
9. Changed logic of lock UI size option
10. Added font and density settings
11. Fixed rare bug when new audio passthrough track can't be start
12. Fixed playback of FLAC and WAV audio tracks
13. Added PCM format setting for choose supported formats
14. Added AC3 decoder
15. Added USB audio settings
16. Added always SDR policy
17. Added new option: enhanced HDR to SDR
18. Some other changes for system stability

2023-05-11 08:16:28

Download 658,4 MB

Android 11 firmware V. 1.1.4 for Ugoos X4 Family

1. Fixed random disconnect Bluetooth remote controller and some other problems
2. Added ability to set sleep timer once; added option to power menu
3. Fixed problem that caused color mode to reset after sleep
4. Fixed some HDMI hotplug errors
5. Fixed synchronization Google account problem

2022-12-21 14:00:22

Download 631.7 MB

Android 11 firmware V. 1.1.0 for Ugoos X4 Family

1. Fixed no sound problem after sleep

2. Fixes of setting for power connect action

3. Some improvements for system automatic frame rate function

4. Fixed playback problems and device reboots on some IPTV channels

5. Fixed no sound in GeForce Now application for Bluetooth devices (need re-pair)

6. Changed key layout for G20 BTS PRO

7. Magisk updated to version 25.1

2022-07-18 14:59:48

Download 614.9 MB

Android 11 firmware V. 1.0.7 for Ugoos X4 Family

Changelog:
1. Fixed formatting some SD cards as device storage
2. Fixed excessive CPU loading after hibernation
3. Fixed voice search after hibernation
4. Fixed AC3 pass-through support for some TVs
5. Fixed system crash when pressing Menu frequently
6. Now music playback does not stop in sleep mode if a Bluetooth or USB audio device is used
7. In system update added option to get pre-release versions
8. Added mouse as a touch input option (Input & devices - Mouse)
9. Changed Magisk dialog in settings
10. Magisk updated

2022-02-05 12:51:08

Download 614.9 MB

Android 11 firmware V. 1.0.6 for Ugoos X4 Family

1. Improvements of automatic frame rate function
2. Fixed error where video size might not fit the screen
3. Fixed GeForce Now freezes
4. Added power indicator settings
5. Added Bluetooth settings
6. Added DTS-HD and TrueHD audio pass-through for hardware audio decoder
7. Fixed synchronization of DTS-HD and TrueHD audio pass-through
8. Improvements of video codecs
9. USearch changes:
    - added sorting and deleting of search results
    - changed results design
    - added settings menu
    - added application launch after clicking on icon (results row)
    - fixed problem of long search for applications
10. Many other changes for system stability

2022-01-14 06:08:49

Download 594.6 MB

Android 11 firmware V. 1.0.5 for Ugoos X4 Family

1. Improvements of IPTV playback
2. Improved automatic frame rate function for H.264 codec
3. Improved work of volume control via HDMI CEC

2021-12-11 09:49:45

Download 589.7Mb

Android 11 firmware V. 1.0.4 for Ugoos X4 Family

1. Added samba server, NFS client, CIFS client (Storage)
2. Added configuration for G20 BTS air mouse
3. Improves of automatic frame rate function
4. Improved Ethernet stability
5. Fixes of HDMI hotplug
6. Fixes of power modes work
7. Fixed pairing bluetooth devices in additional settings
8. Fixed kernel crash for videoplayback with bad frames
9. Fixed kernel crash for HDR10+ videos
10. Fixed work of USearch with some applications
11. Fixed snapshots in recent applications window

2021-12-07 07:39:02

Download 589.7Mb

Android 11 firmware V. 1.0.3 for Ugoos X4 Family

1. Added new voice input application
2. Fixed problem with install Google application
3. Fixed problem with broken cursor after hiding notifications
4. Removed 120 Hz display mode
5. Fixed button manager issue for some remote controllers
6. Fixed problem with authorization in Google applications
7. Audio pass-through improvements
8. Improvements of video codecs
9. Many other changes for system stability

2021-12-07 07:37:20

Download 609Mb

Android 11 firmware V. 1.0.2 for X4 IMG File
